Forged Steel Gate Valve
Forged Steel Gate Valve Manufacturer
MVS Valves’ Forged Steel Gate Valve is engineered to deliver exceptional shut-off performance in high-pressure applications across industries like oil and gas, petrochemical, and power generation. Designed to API 602 and ASME B16.34 standards, this valve ensures tight sealing and smooth flow control in critical service conditions. Manufactured from premium grades such as ASTM A105, A105N, and stainless or alloy steels, it offers long-lasting reliability under extreme pressure and temperature fluctuations.
With a choice of OS&Y or non-rising stem configurations, our API 602 Forged Steel Gate Valves are available with bolted or welded bonnet options, rising stems, and high-quality graphite or PTFE packing. Whether you’re looking for an A105 Forged Steel API 602 Gate Valve Flanged Ends Class 150, or a F304L Forged Stainless Steel API 602 Gate Valve Flanged Ends Class 300, we offer complete flexibility in material and connection types to meet your precise operational needs. For environments that demand corrosion resistance and durability, MVS provides F316L Forged Stainless Steel API 602 Gate Valve Flanged Ends Class 600, along with high-performance alloy steel variants like F11, F22, F5, F9, and F91, suitable for various ends such as socket weld, butt weld, or threaded.
For more demanding conditions, we also manufacture LF2 Forged Carbon Steel API 602 Gate Valve Butt Weld Ends Class 2500, and specialized options such as F51, F53, and F55 Duplex Steel Forged Gate Valves. If you’re operating in aggressive media environments, our exotic alloy range includes Inconel Forged Steel Gate Valve, Monel K400 Forged Steel Gate Valve, and Alloy 20 Forged Steel Gate Valve, ensuring the highest corrosion resistance without compromising on strength. Every valve undergoes rigorous testing to comply with international standards and ensure flawless performance throughout its service life.
Specification
| Specification | Details |
|---|---|
| Valve Type | Forged Steel Gate Valve (OS&Y / Rising‑stem) |
| Size Range | ½″–2″ (DN 15 – DN 50) |
| Pressure Class | Class 800–1500 (API/ASME) |
| Material Grades | ASTM A105 / A105N, F304L, F316L, F11, F22, LF2, F5, F9, F91 |
| End Connections | Threaded, Socket‑Weld, Threaded×Socket Welding, Flanged |
| Bonnet Type | Bolted or Welded Bonnet |
| Standards | API 602, API 600, ASME B16.34; ISO 9001 certified |
| Testing | API 598 shell & seat tested |
| Packing | Graphite or PTFE in gland follower |
Material of Construction
| Body & Bonnet | Forged ASTM A105 / A105N | Stainless Steel F304L/F316L; Alloy Steels F11, F22, F91 |
| Stem | Stainless Steel (commonly 410/420) | 304/316SS or Alloyed SS |
| Gate (Wedge) | Forged Carbon Steel | Stainless or Alloy Steel variants |
| Seat | Metal-to-metal forged seat | Stellited |
| Packing | Graphite (standard) | PTFE, flexible graphite, fire-safe materials |
| Bonnet Bolts | ASTM B7 bolting | Inconel or alloy for high-temp use |
Application Industries
Crude Oil & Natural Gas Industry
Chemical & Petrochemical Industry
Water & Wastewater Treatment
Nuclear & Thermal Power Generation
Food & Beverage Industry
Pharmaceutical & Biotechnology
Pulp & Paper Industry
Mining & Mineral Processing
Marine & Shipbuilding
HVAC & Building Services
Automotive & Paint Chemical Manufacturing
Environmental & Bio Gas Renewable Energy
Steel & Metal Processing
Fertilizer Plants, Polymer Production
Cosmetics & Personal Care
Cement & Construction
Chlor-Alkali Industry
Mineral Acids Industry
Related Valves
Related products
Exporting Reliable Valve Solutions Across Continents
Australia | Argentina | Austria | Bahrain | Belgium | Bulgaria | Canada | Chile | China | Colombia | Czech Republic | Denmark | Egypt | Finland | France | Germany | Greece | Hong Kong | Hungary | Indonesia | Iran | Ireland | Israel | Italy | Japan | Jordan | Kuwait | Korea | Saudi Arabia (KSA) | Lebanon | Lithuania | Malaysia | Mexico | Netherlands | New Zealand | Nigeria | Norway | Oman | Peru | Philippines | Poland | Portugal | Puerto Rico | Qatar | Romania | Russia | Serbia | South Africa | South Korea | Spain | Sweden | Switzerland | Syria | Taiwan | Thailand | Turkey | Ukraine | United Arab Emirates (UAE) | United Kingdom (UK) | United States of America (USA) | Venezuela | Vietnam | Yemen | Zambia
Forged Steel Gate Valve
Frequently Asked Questions
Can’t find your duty condition here? Send us the media, size, pressure and temperature and we will specify the valve. Contact us
What is a forged steel gate valve and how does it work?
A small-bore OS&Y rising-stem gate valve whose body is forged rather than cast. The handwheel raises and lowers a wedge across the bore, and the outside screw keeps the stem thread clear of the media. Forging aligns the grain structure and removes the porosity a small casting can carry, so the same wall thickness holds far higher pressure — which is why forged bodies dominate small-bore high-pressure isolation.
Which body, wedge and seat materials are available?
Body and bonnet in forged ASTM A105 or A105N carbon steel, F304L or F316L stainless, or F11, F22 and F91 alloy steels for elevated temperature service. Seats metal-to-metal, with Stellite hard-facing available where the duty is erosive or the differential high. Specify alloy steel bodies for steam and high-temperature lines where carbon steel would be marginal.
What size, pressure class and end connections apply?
½″ to 2″ (DN 15 – DN 50) in Class 800 to 1500 per API/ASME. End connections threaded, socket-weld, threaded × socket welding, or flanged — the range of connections is deliberately wide because small-bore high-pressure lines are built every way. MVS is ISO 9001:2015 certified.
Forged or cast gate valve — which do I need?
Line size and class decide it. Below 2″ at Class 800 and above, forged is the only sensible construction; a cast body would need far more metal to reach the rating and small castings are harder to keep sound at high pressure. Above 2″, forging becomes uneconomic and the cast stainless gate valve covers ½″–24″ at Class 150–600.
Are you a manufacturer, and what are your minimum order quantity and customization options?
MVS manufactures at its own works — since 1978, ISO 9001:2015 certified — and exports across several continents. The minimum order quantity is 20 pieces. Alloy steel bodies, Stellite-faced seats and specific end connection combinations are built to order.
